Epson dx-10 High speed silent track digital Automatic Wall Inkjet Printerfor wall usage 3 years
Precautions for the use of wall printers:
Please plug in the power plug before using it to ensure that it will not fall off during operation. After the machine is powered on, the red indicator light will light up normally, turn the red button switch to the right, and the green power indicator light will light up normally, that is, the power on is complete!
To turn off this product, please press the middle red rotary button. The green indicator light will go out and the red indicator light will light up, then unplug the power plug!
The detailed parameter as follows.
| Double nozzle wall painting machine specification |
| Model type: | WPM-S2 | |
| Machine body | Aluminum magnesium ,alloy profiles, frame structure |
| Assemble way | movable wheels and slide railway and rapid assemblely |
| Operation | Automatically controlled by computer |
| printhead | epson industrial nozzles x2pcs |
| ink type: | specialized water-base ink for wall printer |
| printing speed | fast | Mode | Speed | |
| medium | sketch mode | 15㎡/h |
| slow | produce mode | 10㎡/h |
| three speed | quality mode | 7㎡/h |
| | Fine mode | 5㎡/h |
| suppying system | negative pressure,400ml ink tank,colors in one unit |
| Technology | VSDT Variable ink drop technique feature technology |
| photo format | support PNG/JPG/TIFF/PDF/PSD/AI AND CDR.ETC |
| Precision | 720x720 DPI/720X1080DPI/720X1440DPI/720X2280DPI |
| Print size | No limite |
| Power supply | AC 110V /220V Frequancy:50hz/60hz |
| power consumption | no load 20w ,load 120w |
| Noise | standby <20DBA ,Working <50DBA |
| Storage | —30 -+60℃ |
| operation | ,-10-+50℃ |
| operation system | window ,xp/ win 7/win8 ,win 10 |
| language | English and chinese |
Daily maintenance of wall painting machine:
Maintenance of main accessories: Print nozzles. Under normal use, check the status diagram of the nozzles every day to confirm whether the nozzles are normal. Check whether the nozzles are normal or not. Check whether the ink cartridges are out of ink and whether the ink tubes are found to be disconnected. If air enters, if the ink cartridges and ink tubes are normal, perform an ink extraction check.
Special situation of wall painting machine:
If you do not use the machine for a long time, you need to remove the nozzle, clean the nozzle, clean the ink and use plastic wrap to seal it.
Weather influence on wall painting machine:
In special weather such as heavy rain and wind, printing will not be performed temporarily.
The circuit board of the wall painter is overheated
After the nozzle is on the machine, check whether the 42V light on the circuit board is on and whether the circuit board heat sink will quickly become hot. If it is hot, turn off the power in time.
